Land Pride LB60

Double tap to zoom



Features

Features Benefits
Reinforced mast Extra sturdiness of the boom mast.
Two lifting lugs Secondary lift lug added in the middle of the boom to increase lifting capabilities when boom is angled forward.
Side plate with holes and slots for stabilizing For use of chain in slots or any other chain or strap in the holes.
Universal skid plate mount Quick set up with your skid steer or track loader.
6,000 lbs capacity Capability of moving a large variety of loads.

Specifications

Model Number LB60
Weight lbs (kg) 384 (174)
Lift capacity lbs (kg) 6000 (2722)
Frame width in (cm) 45 (1.14)
Frame height in (m) 68 (1.73)
Lift lugs in (cm) two lugs, 1 (2.5) plate
Lift lug hole diameter in (cm) For up to 1 (2.5) shackle pins
Side plate in (mm) Slot for 5/16 (8) chain and 3 (76) hole for other chains or straps
Mast in (cm) 6 x 6 (15.2 x 15.2) tube
Reinforced mast in (mm) 1/4 (6) plate
