Call UsNew Holland U80C
Tractor Loaders U80C
Overview:
GROSS HP: 74 HP (55 kW)
OPERATING WEIGHT: 10,916 lbs (4951 kg)
3-POINT HITCH MAX LIFT FORCE: 3,501 lbs (15574 N)
LIFT CAPACITY TO FULL HEIGHT: 6,503 lbs (2965 kg) Long Lip Bucket / 6,537 lbs (2965 kg) 4-in-1 Bucket
Features
PROFIT-MAKING POWER ON THE FRONT AND THE BACK
The New Holland U80D tractor loader gives you versatility that pays. With 74 gross horsepower of clean power with its Tier 4 Final certified engine, you get responsive power at both bucket and hitch for loading, stacking, scraping and leveling. The U80D meets Tier 4 Final certifications by using a Particular Matter Catalyst (PM-Cat) solution. This solution is based on particulate matter’s continuous passive regeneration of soot by NO2 generated on the DOC: C + NO2 = NO + CO/CO2
OPERATOR ENVIRONMENT
WELCOME ABOARD
The large, efficient, flat-deck operator platform provides easy-to-use controls and unobstructed views for outstanding visibility of the work site.
ERGONOMIC CAB DESIGN
- Single lever control
- Fully integrated loader control lever allows the operator to control all loader and front auxiliary functions comfortably in one location
ENGINE AND CHASSIS
POWERFUL ECONOMY
With 74 gross horsepower of clean power with its Tier 4 Final certified engine, you get responsive power at both bucket and hitch for loading, stacking, scraping and leveling. The U80D meets Tier 4 Final certifications by using a Particular Matter Catalyst (PM-Cat) solution. This solution is based on particulate matter’s continuous passive regeneration of soot by NO2 generated on the DOC: C + NO2 = NO + CO/CO2
AXLES AND TRANSMISSION
SMOOTH DIRECTION CHANGES
The smooth synchromesh with power shuttle lets you make smooth direction changes between the four forward and four reverse gears.
SUPERIOR SCRAPING AND LEVELING PERFORMANCE
- The rugged Class II three-point hitch with controllable down pressure provides excellent scraping and leveling performance
- For added versatility, add a 540-rpm power take off (PTO) to run PTO-driven attachments
HYDRAULICS
PLACE LOADS PRECISELY
The curved-arm loader linkage provided on the U80D tractor loader provides hydraulic bucket leveling for less spillback, as well as excellent reach at maximum dump height for truck loading. The unique reverse-mounted loader arm cylinders give you maximum bucket breakout force and superior dump speed on the bucket.
OPTIONAL RIDE GLIDE™
When you add the Glide Ride option, a flip of a switch turns the boom cylinders into the equivalent of giant shock absorbers to stabilize the load while traveling.
OPTIONAL PTO
For added versatility, a 540 rpm hydraulic Power Take Off (PTO) can be added to run PTO driven attachments.
MAINTENANCE
SPEND TIME SAVING MONEY
Routine care is the key to equipment performance and longevity. The D Series tractor loader is designed for fast, easy routine service checks. Easy access is provided to all key fuel, engine, transmission and hydraulic filters, and all engine servicing can now be performed from one side for added convenience.
EASY ACCESS
- One-piece flip-up hood offers full engine access
- All key daily checks are grouped together on one side
- Battery-disconnect and remote jump-start terminals are easily accessible
- Quickly and safely access all key lubrication points on the loader and backhoe from the ground
Specifications
| Model | U80D |
| Loader | |
| Single-lever 5 function control w/ self-leveling and Return-to-Dig | Standard |
| Return-to-dig | Standard |
| In-line, reverse linkage | Standard |
| Dual parallel dump cylinders | Standard |
| Clutch disconnect button on loader control and shift levers | Standard |
| 4-in-1 Bucket - Weight, lbs (kg) | 1451 (658) |
| 4-in-1 Bucket - Heaped, yd³ (m³) | 1.04 (0.80) |
| Engine | |
| Model | F5HFL463D*F005 |
| Type | 4-stroke, turbocharged |
| Cylinders | 4 |
| Bore x stroke, in (mm) | 3.9 x 4.33 (99 x 110) |
| Displacement, in³ (L) | 207 (3.4) |
| Fuel injection | Direct HPCR (High Pressure Common Rail) |
| Engine speeds, (rpm) - Rated speed, full load | 2,200 |
| Engine speeds, (rpm) - Low idle | 900 - 1,000 |
| Engine speeds, (rpm) - High idle, no load | 2,330 - 2,430 |
| Horsepower (SAE J1349) - Gross @ 2,200 rpm, (kW) | 74 (55) |
| Horsepower (SAE J1349) - Net @ 2,200 rpm, (kW) | 68.4 (51) |
| Maximum torque @ RPM - Gross, lb-ft (Nm) | 233 (316) |
| Maximum torque @ RPM - Net, lb-ft (Nm) | 219 (298) |
| Torque rise at rated speed | 35% |
| Powertrain | |
| Transmission type | 4 speed synchromesh with hydraulically actuated clutches and electric F/R shuttle control, clutch disconnect buttons on the transmission shifter and loader control lever |
| Torque converter ratio (standard) | 3:1: |
| Torque converter (PTO ready) | 3:2:1 |
| Differential-lock | On the go push-button activation |
| Service brakes | Individually applied hydraulically actuated, maintenance-free, self-adjusting outboard mounted wet disc |
| Parking brakes | Trans Mounted SAHR (Spring Applied Hydraulic Release) |
| Travel speeds, mph (km/h)* | 1st, 2nd, 3rd, 4th |
| Forward/Reverse (standard) | 3.8 (6.1), 6.1 (9.8), 12.8 (20.6), 24 (38.6) |
| Forward/Reverse (PTO Ready) | 3.5 (5.6), 5.5 (8.9), 11.8 (19), 21.3 (34.3) |
| Electrical | |
| Alternator, amps | 120 |
| Tires | |
| Rear | 2/4 WD-17.5 L x 24, 10-ply rating STD, 2/4 WD-19.5 L x 24, 10-ply rating OPT |
| Service Capacities | |
| Fuel tank, gal (L) | 30 (114) |
| Hydraulic system, gal (L) - Total | 19 (72) |
| Hydraulic system, gal (L) - Reservoir w/filter | 15.3 (58) |
| Hydraulic system, gal (L) - Reservoir w/o filter | 14.8 (56) |
| Rear Axle, qt (L) - Planetaries (each) | 1.6 (1.5) |
| Engine oil w/filter, qt (L) | 8.5 (8) |
| Cooling system, qt (L) | 17 (16.1) |
| 3-Point Hitch | |
| Variable flow from 0 to 8 gpm (0 to 30 L/min) | Standard |
| 485 lbs (220 kg) counterweight included with hitch | Standard |
| Hitch position - 1/5 lbs (N) | 3247 (14,444) |
| Hitch position - 2/5 lbs (N) | 3400 (15,125) |
| Hitch position - 3/5 lbs (N) | 3501 (15,547) |
| Hitch position - 4/5 lbs (N) | 3297 (14,666) |
| Hitch position - Highest point lbs (N) | 2984 (13,274) |
| Weight | |
| Base Unit lbs (kg) | 10,916 (495) |
* Travel speeds at 2,293 engine rpm with 19.5 L x 24 rear tires
** Turning diameter dimensions are curb to curb w/82” (2.08 m) general purpose bucket.
*** Hitch position is vertical distance of lowest hitch point above ground.
**** Unit configuration: 82” standard bucket, 2WD, 19.5L x 24 rear tires, ROPS cab, Suspension seat, dual batteries, no operator.
