Woods BB72.50

Double tap to zoom



Features

  • Three-point hitch: CAT 1 & 2, quick-hitch ready
  • Cuts brush up to three inches in diameter
  • Six-year limited gearbox warranty includes the seals
  • 12.7 inches deep, with half-inch by four-inch blades, and rear baffling that work together to evenly cut and distribute large amounts of material, for a superior cut quality
  • Comes standard with adjustable driveline hanger making it easier to attach
  • Greasable Quick-change blade pins are easy to maintain and remove from top of the deck through large blade access window
  • High-strength steel bumper with a Z-channel frame for added durability when backing over tough brush
  • NOTE: All gearbox horsepower ratings listed in the following specifications are based on Woods’ field testing.

Specifications

Tractor PTO HP 30-150
Tractor Hitch CAT 1 and 2 clevis
Cutting Height Range (in) 2 to 12
Cutting Capacity Diameter (in) 3
Cutting Width (in) 72
Blade Tip Speed (fpm) 15,900
Weight (lbs) 1,125
Deck Thickness (in) .135 (10 ga)
Side Frame Thickness (in) 0.25
Side Frame Depth (in) 12.7
Transport Width (in) 79.3
Output Shaft Diameter (in) 2
Overall Width /Length (in) 112
Deck Construction Smooth top, sloped
Gearbox HP 150
*Gearbox horsepower ratings listed are based on field testing.
Blade Dimensions (in) 1/2 x 4
Frame and Deck Support (in) 3 x 3 tube
Tractor PTO Speed (rpm) 540
Quick-hitch Compatible Yes
Blade Carrier Diamond stump jumper, optional round
Driveline Protection Slip-clutch
Skid Shoes Full-length, replaceable
Rear Bumper Z-channel
Options Rubber belting/steel band or chain shielding; check chains, dual tailwheel: round stump jumper
